- Extra heavy duty aluminum HolsterTop with thick side plates
- Shoulder bolt and lock nut on top hinge; 4 solid aluminum rivets attach top to each front rail
- Slip-resistant TRACTION-TRED® steps are single riveted and have extra wide knee braces
- Heavy duty internal spreaders
- Full set of rear horizontals spaced one per foot
- GLAS*MARK® Violator stripes on rails allow ladder to be more visible
- EDGE® bracing system helps to decrease damage to rail
- Molded external rail shield helps protect against abrasion damage
- Slip-resistant foot pads attached to the EDGE® structure
- Plastic external rail shield helps protect against abrasion damage
- Every rivet backed up by metal, metal plates or washers to protect rails
- Optional manual pail shelf kit, model no. PK76-9 or automatic closing pail shelf kit model no. 76-2
Interested in this item or want more information?
Hours:
Phone: 419-243-9144
Email: gogel.fastener@gmail.com
Can't find what you want? Give us a call and we can help you find it.
Details
Specifications
| Feature | Size / Details |
|---|
| Size | 10 ft |
| Reach Height | 14 ft |
| Max. Standing Height | 7 ft 8 in |
| Description of Top Features | Parts tray, 2 drill holes, 2 tool slots, 3 tool holes |
| Edge Bracing | Heavy |
| Load Capacity | 375 lbs |
| Type | Type IAA Duty Rating |
| Performance Rating | |
| Material | Fiberglass |
| Approx. Width | 32 in |
| Approx. Spread | 66-5/8 in |
| With Pail Shelf | No |
| Spreader Material | Steel |
| Certifications | ANSI A14.5 (2007); OSHA |
| Approx. Cu. Ft. Per Unit | 11.4 |
| Approx. Shipping Wt. Lbs. | 40.5 |
Additional Information
Manufacturer: Werner Ladder
