- HolsterTop with Lock-In System secures tools to increase productivity
- Shoulder bolt and nut on top hinge
- 4 rivets attach top to each front rail
- Double riveted slip-resistant TRACTION-TRED® steps
- Back-up plates reinforce all top connectors
- Heavy duty internal spreaders
- Full set of rear horizontals spaced one per foot
- All steps and two rear horizontals are knee-braced
- Slip-resistant foot pads attached to the EDGE® structure
- Every rivet backed up by metal, metal plates or washers to protect rails
- Optional manual pail shelf kit, model no. PK76-9 or automatic closing pail shelf kit model no. 76-2
Interested in this item or want more information?
Hours:
Phone: 419-243-9144
Email: gogel.fastener@gmail.com
Can't find what you want? Give us a call and we can help you find it.
Details
Specifications
| Feature | Size / Details |
|---|
| Size | 6 ft |
| Reach Height | 10 ft |
| Max. Standing Height | 3 ft 10 in |
| Description of Top Features | Paint tray slot, can hook, Lock in accessory sockets, 2 tool holes, drill hole, pint, quart and gallon paint can, 2 parts trays, tape measure slot |
| Edge Bracing | Heavy |
| Load Capacity | 300 lbs |
| Type | Type IA Duty Rating |
| Performance Rating | |
| Material | Fiberglass |
| Approx. Width | 23-3/8 in |
| Approx. Spread | 41-1/4 in |
| With Pail Shelf | Yes |
| Spreader Material | Steel |
| Certifications | ANSI A14.5 (2007); OSHA |
| Approx. Cu. Ft. Per Unit | 5.3 |
| Approx. Shipping Wt. Lbs. | 22 |
Additional Information
Manufacturer: Werner Ladder
